Metriso 3000 Test Kit

Metriso® 3000 – test kit

• Suitable for resistance point-to-point and resistance to ground measurements
• Integrated data logger with USB communication port for data transmission (50.000 test values). The supplied Report Generating Software ETC allows to generate a complete test report
• Humidity and temperature sensor
• A barcode scanner can be used in order to record measurement points before testing
• Menu language: German/English/French/Spanish

• Test voltage / Test current: 1 mA <= I <= 1,3 mA
  • High ohmic range: DC 10 volts,100 volts and 500 volts
• Test range:
  • low ohmic range: 0 to 10 kOhm
  • high ohmic range: 1 kOhm to 1,2 TOhm
• Operation: Battery operated
• Probes:
  • 2 x Model 850 (weight: 2,27 kg / ø 63,5 mm) with conductive rubber,
  • 1 x hand-held probe Model 45
• complies with IEC 61340-4-1, IEC 61340-2-3, IEC 61340-4-5

• digital high resistance tester
• temperature and relative humidity sensor
• USB port
• PC software for Windows®
• 2 probes
• a hand-held probe with connecting cable
• user’s instructions in German, English and French
• calibration certificate
• conductive carrying case fitted with dissipative pink foam

Metriso 3000
